How to Design a Right Angle BNC Connector in KiCad Designing RF circuits on PCBs requires careful attention to component selection and layout. Right angle BNC connectors are essential for space-saving designs while maintaining excellent signal integrity for oscilloscopes, video equipment, and RF test setups. This comprehensive guide walks you through creating and implementing right angle BNC connectors in KiCad, from footprint selection to final PCB layout.

Whether you’re building test equipment, video distribution systems, or RF measurement tools, understanding how to properly integrate these connectors will ensure your designs perform reliably at high frequencies.

Understanding Right Angle BNC Connectors for PCB Design

Right angle BNC connectors mount perpendicular to your PCB, offering several key advantages over straight connectors. They reduce the overall height profile of your device, improve cable routing by directing connections parallel to the board edge, and minimize mechanical stress on the board when cables are connected or disconnected.

These connectors come in two main mounting styles: through-hole technology (THT) and surface-mount (SMD). THT versions provide superior mechanical stability and are ideal for applications with frequent cable connections. They typically feature multiple pins: a center conductor for the signal, a shield connection for ground, and mechanical stability pins that secure the connector to the board.

Most RF applications use connectors designed for either 50Ω or 75Ω impedance. Video and broadcast equipment typically uses 75Ω, while test equipment and RF communications favor 50Ω. Selecting the correct impedance matching for your application is critical for signal integrity.

Common applications include bench test equipment, oscilloscope inputs, video signal distribution, RF function generators, and spectrum analyzer connections. The right angle configuration is particularly valuable when board space is limited or when you need clean cable management in rack-mounted equipment.

Step 1: Finding or Creating the Correct BNC Footprint

Option A: Using a Pre-made KiCad Library (Recommended)

For most projects, using an existing library is the fastest and most reliable approach. The official KiCad library repository contains several BNC connector footprints that have been verified by the community.

Start by opening KiCad’s Preferences menu and navigating to Manage Footprint Libraries. Check if you have the Connector_Coaxial library enabled. This library includes several right angle BNC options with proper pad sizing and mechanical clearances already defined.

Würth Elektronik provides an excellent free library for KiCad that includes their WR-BNC connector series. These footprints include comprehensive 3D models and are based directly on manufacturer specifications. You can download their library from the Würth Elektronik website and add it to your KiCad installation.

When browsing for footprints, look for part numbers that match your intended connector. Common models include the TE Connectivity 1-1337543-0 series and Amphenol RF right angle jacks. The footprint name should clearly indicate whether it’s designed for THT mounting and specify any unique characteristics.

Option B: Building a Custom Footprint from a Datasheet

Sometimes you need a specific connector model that doesn’t have a pre-existing KiCad footprint. Creating a custom footprint requires careful interpretation of the manufacturer datasheet, but the process ensures perfect compatibility with your chosen component.

Begin by obtaining the official datasheet for your connector. Search for the mechanical drawing section, which typically shows a top-down view with all pad locations dimensioned. Look for critical specifications including the center conductor pin position, shield pin locations, mounting hole or stability pin positions, pad diameters for each pin type, and recommended PCB clearance areas.

Open KiCad’s Footprint Editor and create a new footprint. Name it clearly using the manufacturer part number. Set your grid to 0.5mm or finer for precise pad placement. Most datasheets dimension from a reference point, usually the center of the main signal pin.

Start by placing the center conductor pad. This is your signal connection and typically requires a specific pad size to ensure proper impedance transition. The datasheet will specify both the finished hole size and the pad diameter. BNC connectors often use a 1.0mm to 1.3mm hole with a 2.0mm to 2.5mm pad.

Next, add the shield pins. These provide the ground connection and are critical for RF performance. They’re usually positioned symmetrically around the center pin. The shield connection must have low impedance to your ground plane, so ensure adequate pad size and proper via placement in your final layout.

Many right angle BNC connectors include mechanical stability pins marked as P1*2 or similar in the datasheet. These are larger pins or mounting posts that don’t carry signal but prevent the connector from rotating or lifting during use. Place these as through-hole pads with the dimensions specified in the datasheet. While these should connect to ground for best shielding, they’re not the primary electrical ground path.

Add a courtyard outline that extends beyond the connector body by at least 0.25mm. This helps KiCad’s design rule checker prevent component overlap. Draw the fabrication layer outline showing the connector’s physical footprint, which helps during assembly and troubleshooting.

Include reference designator and value text on the silkscreen layer, positioned where they won’t be covered by the connector body. Save your footprint with a descriptive name including the manufacturer and part number.

Step 2: Assigning the Footprint in the Schematic

Creating the schematic symbol and linking it to your footprint is where many designers encounter confusion. The key is understanding which pins carry signals versus mechanical functions.

In KiCad’s schematic editor, place a BNC connector symbol from the Connector library. The standard symbol shows two pins: the center conductor (signal) and the shield (ground). This simplified representation works well for most applications.

Right-click the symbol and select Properties, then navigate to the Footprint assignment. Browse to your chosen footprint, whether from a library or your custom creation. Click OK to establish the link.

Here’s the critical part that trips up many users: your schematic symbol has two electrical connections, but your physical footprint may have four, five, or more pads. KiCad handles this through pin mapping in the footprint definition. The center conductor schematic pin maps to the physical center pin. The shield schematic pin maps to all shield pads and mechanical support pins simultaneously.

When you generate the netlist, KiCad will connect all pads marked as shield or mechanical support to your ground net. This is the correct behavior. The large mechanical pads labeled P1*2 in many datasheets exist for physical stability but are electrically connected to ground to maintain shielding effectiveness.

If you’re working with a more complex connector that has separate shield and mechanical ground pins, you may need to modify the schematic symbol to include additional pins or verify that the footprint’s pin definitions match your expectations.

Step 3: PCB Layout and Routing Best Practices

Placing the Connector and Managing Constraints

Right angle BNC connectors mount at the board edge with the connector body extending beyond the PCB outline. Position your connector so the mounting pads are on the board but the keep-out area extends past the edge cut.

Maintain adequate clearance from other components. High-frequency signals are sensitive to nearby conductors, so keep at least 5mm clearance from adjacent circuitry where possible. Check your connector’s datasheet for recommended keep-out zones on both the top and bottom layers.

Consider mechanical access. Users need to plug and unplug cables, so ensure nothing blocks the connector opening. Panel-mounted designs should align the connector with the opening in your enclosure.

Routing the RF Trace for Optimal Performance

The trace connecting your BNC center pin to your circuit determines your signal integrity. For a 50Ω impedance, calculate the required trace width based on your PCB stackup. KiCad includes a PCB Calculator tool under the Tools menu that computes controlled impedance trace dimensions.

For a typical 1.6mm FR4 board with 1oz copper, a 50Ω microstrip trace on the surface layer is approximately 3mm wide with a solid ground plane on the layer beneath. Verify this calculation with your specific board parameters.

Route your RF trace as short and straight as possible. Every bend, via, and discontinuity creates impedance changes that degrade signal quality. If you must turn, use 45-degree angles rather than 90-degree corners to minimize reflections.

Maintain a continuous ground plane beneath your entire signal path. The return current flows in the ground plane directly under your signal trace. Any gaps or splits in this plane force current to take longer paths, increasing inductance and degrading performance.

Minimize vias in the RF path. If you must change layers, place a ground via immediately adjacent to the signal via. This provides a short return path and maintains the impedance as closely as possible. Use multiple ground vias around your connector’s shield pins to create a low-impedance connection to your ground plane.

Connect the shield pins to your ground plane with generous copper pours or multiple vias. The shield connection should have the lowest possible impedance at your operating frequency. For frequencies above 1 GHz, consider stitching vias around the connector area to create a virtual shield wall.

Common Pitfalls and How to Avoid Them

One frequent mistake is selecting a footprint that doesn’t match the physical connector. Always cross-reference the manufacturer part number between your component and the KiCad footprint. Even small dimensional errors can make a connector impossible to mount or result in poor solder joints.

Poor ground connections cause more RF problems than any other single issue. Ensure your shield pins connect to a solid ground plane with multiple vias. A single thin trace to ground creates inductance that degrades shielding effectiveness. The shield should connect to ground with an impedance of less than one ohm across your frequency range.

Ignoring mechanical support pins leads to reliability problems. Those large pads marked as mechanical or mounting pins prevent the connector from rotating or lifting when cables are connected. While they’re not the primary electrical path, they should still connect to ground and must be soldered properly.

Inadequate PCB edge clearance prevents proper connector mounting. Check your board manufacturer’s edge clearance requirements and ensure your connector pads are sufficiently far from the board edge to avoid manufacturing issues. Typically, maintain at least 0.5mm from the edge cut to any pad or trace.

During the testing phase, verify continuity between your circuit ground and the connector shield using a multimeter. Poor shield grounding often doesn’t cause obvious failures but degrades signal quality and increases susceptibility to interference.

Neglecting impedance control results in signal reflections and reduced bandwidth. Calculate your trace width correctly and maintain consistent geometry throughout the signal path. Even a short section of mismatched impedance can cause significant signal degradation at high frequencies.

Recommended Right Angle BNC Connector Models

These connectors are widely available through distributors including Digi-Key, Mouser Electronics, RS Components, and Farnell. Always verify the current availability and specifications with your preferred supplier, as manufacturers occasionally revise designs or introduce improved versions.

Frequently Asked Questions

What is the SHIELD pin on a BNC connector footprint?

The SHIELD pin is the primary ground connection on your BNC connector. It connects to the outer conductor of the coaxial cable and must tie directly to your PCB’s ground plane. This shield provides electromagnetic shielding that prevents interference from entering or leaving your signal path. Without a proper shield connection, your RF performance will suffer from noise and potential oscillation. Connect the shield to ground using multiple vias and a large copper area to minimize impedance.

What do the extra large pads (P1*2) mean on my BNC footprint?

These pads are mechanical stability or mounting pins. They’re not part of the primary electrical signal path but provide physical support to prevent the connector from rotating, tilting, or pulling away from the PCB during cable insertion and removal. While they should be connected to ground for electromagnetic shielding purposes, they don’t need to carry significant current. The larger size accommodates bigger pins that provide mechanical strength. Always solder these pins even though they’re not electrically critical, as they’re essential for reliability.

Can I use a surface-mount (SMD) right-angle BNC connector?

Yes, SMD right angle BNC connectors are available and suitable for higher-frequency applications where you want to minimize the via transitions to internal layers. SMD versions typically have lower profile and can be assembled with automated pick-and-place equipment. However, they offer less mechanical stability than THT versions, making them less suitable for applications with frequent cable connections. For bench test equipment that sees daily use, THT remains the better choice. For embedded systems with semi-permanent cable connections, SMD can work well.

How do I ensure good signal integrity with a right-angle BNC on my PCB?

Good signal integrity requires controlled impedance throughout your signal path. Start by calculating the correct trace width for your target impedance using your board stackup parameters. Maintain this width consistently from the connector to your destination. Ensure a continuous ground plane beneath the entire trace path with no gaps or splits. Minimize the trace length and avoid unnecessary vias or bends. Connect the connector shield to ground with multiple vias placed symmetrically around the connector. The shorter and more direct your signal path, the better your high-frequency performance will be.

Where can I find free KiCad libraries for BNC connectors?

The official KiCad library repository on GitHub includes Connector_Coaxial, which contains several BNC connector footprints. Many connector manufacturers provide free KiCad libraries for their products, including Würth Elektronik, TE Connectivity, and Amphenol RF. These manufacturer libraries often include 3D models and are based directly on their datasheets, ensuring accuracy. You can also find community-contributed libraries on GitHub and the KiCad forums. Always verify any third-party footprint against the actual datasheet before using it in production designs.

Conclusion

Implementing right angle BNC connectors in KiCad requires attention to detail in both footprint selection and PCB layout. By following the steps outlined in this guide, you’ll create reliable, high-performance RF connections that maintain signal integrity while saving board space.
